Description
Buy T-Type Angle Seat Valve JCV1 0-16bar Stainless Steel CF8M Threaded Pneumatic Actuated
The JCV1 T-Type Pneumatic Angle Seat Valve from VALVEHU is a precision-engineered control valve designed for demanding flow applications involving neutral gases, air, water, and steam. Crafted from high-quality stainless steel materials including CF8, 304, and CF8M/316, this industrial valve ensures excellent corrosion resistance and durability in challenging environments. Featuring a T-type body structure and pneumatic actuation, it offers reliable operation in automated process systems where quick on-off and throttling control are essential.
The valve supports both single-acting and double-acting operation, making it highly adaptable for a wide range of process control needs. It performs within a pressure range of 0 to 16 bar and is engineered to handle media temperatures from -10°C to +180°C, with environmental tolerance up to +60°C. This makes it suitable for various industrial sectors such as chemical processing, water treatment, food and beverage, and pharmaceutical applications.
Internally, the JCV1 features a PTFE sealing system, providing high resistance to temperature and chemical aggression, while the actuator housing is constructed from PA (polyamide) for long-term performance and mechanical strength. Available in threaded connection design, it ensures ease of installation in new or retrofit systems. Valve sizes range from DN15 to DN100 (½” to 4″), offering flexibility for various flow capacities.
Whether you are optimizing fluid control in compact piping layouts or upgrading pneumatic flow systems, this valve stands out for its robustness and operational efficiency. To explore this model or any other industrial valves tailored to your requirements, feel free to contact the experts at VALVEHU in China. We are here to support your engineering and sourcing needs with trusted valve solutions.
Technical Specifications
Body Material: CF8, 304, CF8M/316 stainless steel
Seal Material: PTFE (Polytetrafluoroethylene)
Actuator Housing: Reinforced PA (Polyamide)
Connection Type: Threaded
Pressure Range: 0 to 16 bar
Media Temperature: -10°C to +180°C
Ambient Temperature: -10°C to +60°C
Valve Size Range: DN15 to DN100 (½” to 4″)
Actuation Type: Pneumatic, single or double acting
Suitable Media: Neutral gases, air, water, steam
FAQ
What media can the JCV1 angle seat valve handle?
It is designed for neutral gases, compressed air, water, and steam.
Is the JCV1 valve suitable for high-temperature applications?
Yes, it supports media temperatures up to 180°C and ambient up to 60°C.
What is the actuation method used in this valve?
It operates using a pneumatic actuator, either single-acting or double-acting.
What type of seal is used in the JCV1 valve?
It uses a PTFE seat, known for high chemical and thermal resistance.
Does the JCV1 valve come in multiple sizes?
Yes, it is available from DN15 to DN100, suitable for a wide range of flow capacities.
